Torelco QEG
James and Matt at Torelco

ORDER QEG PARTS FROM TORELCO!

Torelco offers a fully processed core and supplemental kit to complete your QEG generator, or you can buy parts separately. The photo above depicts an epoxied core. Non-epoxied cores are also available

Please refer to the QEG Free Energy Generator Plans/Manual for detailed descriptions and photos of parts listed below.

Processed Core (delivered):

Generator Core, 12″ OD X 6″ ID, 15″ overall, 3-1/2″ stack, 84 lbs.
Spacer Blocks, Aluminum 6061-T6, 1-1/2″ X 1-1/2″ X 4-1/2″
Mica Tape, VonRoll 77956 Mica Mat, Polyester Resin Bonded 1″
Mica Plates, 2.25″ X 4.5″ X .030″, ‘C’ shape, prefabricated
Nomex corner insulation, hand cut
Tape, black, 1″ reinforced, high-strength
Sleeving, fiberglass w/PVC, for magnet wire
Tubing, Teflon, for #20 HTAIHSD
Tubing, Teflon, for #12 HTAIHSD
Magnet wire, HTAIHSD #20 RD NAT REA – Pulse Shield – Heavy MW35, 73, 36
Magnet wire, HTAIHSD #12 RD NAT REA – Pulse Shield – Heavy MW35, 73, 36
Tape, white, 1″ fiberglass, hi-temp
2X4s, plywood, misc. shipping pallet materials
Core complete. Processed and secured for shipping

Parts Kit Description (1 system):

7/8″ Shaft
Bonding Compound #648 50 ml
Primer/Activator #7471 4.5 oz.
Bearings
Bearing Hardware Kit
End Plates
End Plate Hardware Kit
Shrouds
Shroud Hardware Kit
V-Belt 4L430
Pulley AK30 x 7/8
Pulley AK25 x 7/8
DC PM Variable Speed Motor 90/180V Armature
Motor Mounting Hardware Kit
Variac – Staco 1520CT
Bridge Rectifier
Switch
Capacitors 940C30P15K-F
Terminal Lug T&B L70
Drill Rod, 1/4″ [6.35mm]Ø, Type A2, 1-18″ L
Platform (Base), Laminate, 18″ x 36″ x 1-1/2″
Core Mounting Shoe, Laminate, 15″ x 6-1/2″ x 1-1/2″
Core Mounting Shoe Hardware Kit
Exciter Coil Assembly

Torelco is working with FTW on best pricing and accessibility of parts available. Please contact Matt Peterson at mpeterson@torelco.com and include “QEG” in the subject line so we can expedite your order.

We are happy to provide this service and thank you for your patience in awaiting a reply to your inquiries.
